FEATURES
- Receiver Power-On indication (single beep).
- Transmitter Turn-On indication (double beep).
- Frequency in-use indication (triple beep).
- Lost Model Alarm (continuous multiple-beep).
- Battery Saver Warning Alarm if Receiver is left switched
on (and transmitter is off).
- Compatible with most 2 channel (or more) AM/FM radio control
receivers.
- Quality built-in servo extension lead (no extra 'Y' lead
required).
- Highly reliable microprocessor control.
- Also alerts user to receiver or transmitter battery very
low. Receiver out-of-range and faulty aerial connections.
SPECIFICATIONS
- SIZE: Approx 16mm round x 20mm deep
- WEIGHT: <10 grams
- WORKING VOLTAGE: 3 to 5.5 Vdc
- CURRENT CONSUMPTION: <2mA (max) standby, <12.5mA (max)
in alarm
- SOUND OUTPUT LEVEL: Loud 80dB (typical) @ 1 meter
- CONNECTION: Plug in-line between receiver and any servo
(can replace extension lead) OR...plug into any spare servo
channel on receiver. Plug in-line with CH1 or CH2 servo
to get reliable results when using the Frequency-in-use
indication.
- COMPATIBILITY: LMA-1 is for use with JR, HiTec, and Futaba,
1.5mS centred AM or FM radio gear. The supplied connector
lead has been modified to fit all these.
- Will not work with PCM receivers.
|
